ZNSE

ZNSE

 Zinc Selenide,(ZnSe) a chemically vapor deposited material, is the material of choice for optics used in high power CO2 laser systems due to its low absorption at 10.6µm. However it is also a popular choice in systems operating at various bands within its wide transmission range. ZnSe has a high resistance to thermal shock making it the prime material for high power CO2 laser systems. ZnSe however is only 2/3 the hardness of ZnS multi-spectral grade but the harder anti-reflectance coatings do serve to protect ZnSe. Zinc Selenide’s cost is about the same as ZnS multi-spectral grade and is generally more expensive than Germanium.




Znse
Znse
Size:  Dia10mm to 150mm
Tolerance:  +0/-0.1
Surface Quality :  40/20 or 20/10 precision
Flatness :  1/4 lambda per inch @633nm, 1/8 lambda per inch @633nm
Parallelism : < 3 arc min
Chamfer : 0.25(+0.25/-0.00)mm × 45 Degree
Material :  Znse
